Name: Assembled Tesla Battery Box Module (2-5 Modules) - Batteries included
SKU: 2745
Availability: InStock

Assembled Tesla Battery Box Module (2-5 Modules) – Batteries included

We are now offering our assembled and loaded battery boxes for Tesla modules!

Features:

Battery modules included
Compact – 29″ length x 12-3/8″ wide. Height is dependent on the number of modules (approximately 3-1/8″ per module)
High quality 1/4″ 6061 Aluminum construction
Pre-assembled, tested and ready to install!
Pre-wired for Orion BMS cell taps and thermistors
Includes high power plugs and BMS plug (We will need to know your system configuration to wire these correctly)
Includes coolant fittings (6AN) installed and internally plumbed for liquid cooling
Easy mounting – All holes can be used for mounting. Remove the existing bolts and replace with the proper length bolts (3/4″ + thickness of mount material).
Powder coated or Natural finish

Please contact us with any questions prior to ordering.

Freight not included. Please contact for a freight quote.

CAD Models
